Specifications

• Dimensions

  add remove
  • Length:
    96.9 in
  • Ground clearance:
    4.9 in
  • Rake (steering head):
    26
  • Trail:
    6.8 in
  • Wheelbase:
    64.0 in
  • Tires, front specifications:
    BW 130/60B21 M/C63H
  • Tires, rear specifications:
    BW 180/55B18 M/C80H
  • Fuel Capacity:
    6.0 gal
  • Oil capacity:
    4.9 qt.
  • Weight, as shipped:
    860 lbs
  • Weight, in running order:
    893 lb. (405 kg) lb
  • Luggage capacity – volume:
    2.4 cu ft (0.068 m3)
• Engine

  add remove
  • Engine:
    Milwaukee-Eight® 117
  • Bore:
    4.1 in
  • Stroke:
    4.5 in
  • Displacement:
    117.35 in³
  • Compression ratio:
    10.2:1
  • Fuel system:
    Electronic Sequential Port Fuel Injection (ESPFI)
  • Exhaust:
    Dual, with crossover
• Performance

  add remove
  • Engine torque testing method:
    J1349
  • Engine torque:
    126.1 ft-lb
  • Lean angle, right (deg.):
    33.7
  • Lean angle, left (deg.):
    33.9
  • Fuel economy:
    0.00 mpg
• Powertrain

  add remove
  • Primary drive:
    Chain, 34/46 ratio
  • Engine torque:
    126.1 ft-lb
  • Gear ratios (overall) 1st:
    9.593
  • Gear ratios (overall) 2nd:
    6.65
  • Gear ratios (overall) 3rd:
    4.938
  • Gear ratios (overall) 4th:
    4
  • Gear ratios (overall) 5th:
    3.407
  • Gear Ratios (overall) 6th:
    2.875
• Chassis

  add remove
  • Wheels, front type:
    Gloss Black and Contrast Smoked Satin Knockout
  • Wheels, rear type:
    Gloss Black and Contrast Smoked Satin Knockout
  • Brakes, caliper type:
    32mm, 4-piston fixed front and rear
• Electric

  add remove
  • Lights (as per country regulation), indicator:
    High beam, turn signal indicator, neutral, low oil pressure, check engine, security/fault indication, battery, low fuel warning, cruise control, ABS, tire pressure monitoring system indicator, traction control, rain mode, vehicle hold control
  • Gauges:
    Custom gauges styled to complement each CVO vehicle. Display features odometer, trip A, trip B, range to empty and gear indicator; and larger tell-tale indicators.
• Wheels/ Tires

  add remove
  • Front:
    D408F
  • Rear:
    D407
