Specifications

• ENGINE

  add remove
  • Engine Type:
    Horizontal In-line
  • Cylinders:
    4
  • Engine Stroke:
    4-Stroke
  • Cooling:
    Liquid
  • Valves:
    16
  • Valves Per Cylinder:
    4
  • Valve Configuration:
    DOHC
  • Bore (in):
    2.99
  • Stroke (in):
    2.17
  • Displacement (cc):
    999.8
  • Carburetion Type:
    Fuel Injected
  • Turbocharged:
    No
  • Supercharged:
    No
  • Bore And Stroke:
    76mm x 55mm
  • Induction:
    Programmed Dual Stage Fuel Injection (PGM-DSFI) with 48mm throttle bodies, Denso 12-hole injectors
  • Ignition:
    transistorized with electronic advance
  • Compression Ratio:
    13:1
  • Valve Train:
    DOHC; four valve per cylinder
  • Final Drive:
    #530 Chain; 16T/43T
• Chassis/ Suspension/ Brake

  add remove
  • Front Suspension:
    43 mm Big Piston Front Fork with preload, compression rebound adjustment; 4.3 inches of travel
  • Rear Suspension:
    Single shock; 5.2 inches of travel
  • Front Brake:
    Dual radial-mounted four-piston calipers with full-floating 320mm discs
  • Rear Brake:
    Single-caliper 220mm disc
  • Front Tire:
    120/70-17
  • Rear Tire:
    190/50-17
• Dimensions

  add remove
  • Rake:
    23.3 degrees
  • Trail:
    3.8 inches
  • Wheelbase:
    55.3 inches
  • Seat Height:
    32.3 inches
  • Curb Weight:
    430 pounds (Includes all standard equipment, required fluids and full tank of fuel—ready to ride)
  • Fuel Capacity:
    4.3 gallons
  • Miles Per Gallon:
    38 MPG - Honda's fuel economy estimates are based on EPA exhaust emission measurement test procedures are intended comparison purposes only. Your actual mileage will vary depending on how you ride, how you maintain your vehicle, weather, road c
• Other

  add remove
  • Emissions:
    Meets current EPA standards. California version meets current CARB standards and may differ slightly due to emissions equipment.
• Factory Warranty Information

  add remove
  • Warranty:
    Transferable, unlimited-mileage limited warranty
• TRANSMISSION

  add remove
  • Transmission Type:
    Manual
  • Number Of Speeds:
    6
  • Primary Drive (Rear Wheel):
    Chain
  • Reverse:
    No
• TECHNICAL SPECIFICATIONS

  add remove
  • Wheelbase (in):
    55.3
  • Fuel Capacity (gal):
    4.2
  • Length (in):
    81.3
  • Width (in):
    28.3
  • Height (in):
    44.3
  • Ground Clearance (in):
    5.1
  • Wet Weight (lbs):
    430
• SUSPENSION

  add remove
  • Front Suspension Type:
    Inverted Fork
  • Front Suspension Size (in):
    1.6
  • Front Travel (in):
    4.7
  • Front Adjustable Fork Pre-Load:
    Yes
  • Front Adjustable Rebound Damping:
    Yes
  • Front Central Suspension Strut:
    No
  • Steering Damper:
    Yes
  • Rear Suspension Type:
    Twin Sided Swing Arm
  • Rear Suspension Material:
    Aluminum
  • Rear Travel (in):
    5.2
  • Rear Adjustable Shock / Spring Pre-Load:
    Yes
  • Rear Adjustable Rebound Damping:
    Yes
  • Number Rear Shock Absorbers:
    1
  • Rear Suspension Brand Name:
    Pro Link®
  • Air Adjustable:
    No
  • Front Suspension Brand Name:
    Showa®
• WHEELS & TIRES

  add remove
  • Wheels Composition:
    Aluminum
  • Chromed:
    No
  • Front Tire (Full Spec):
    Dunlop® Sportmax 214F: 120/70R 17
  • Rear Tire (Full Spec):
    Dunlop® Sportmax 214: 190/50R 17
  • Spare Tire:
    Not Available
• BRAKES

  add remove
  • Front Brake Type:
    Dual Hydraulic Disc
  • Front Brake Diameter (in):
    12.6
  • Rear Brake Type:
    Hydraulic Disc
  • Rear Brake Diameter (in):
    8.7
  • Anti-Lock Brakes:
    Not Available
  • Linked Brake System Front to Rear:
    Not Available
  • Brake Brand Name:
    Tokico®
